Process Analytik Instruments Pvt. Ltd. is a trusted Polymer Viscometer Distributor, providing high-precision instruments for accurate viscosity measurement in polymer processing. Our viscometers ensure reliable performance, efficiency, and consistency, making them ideal for research labs and industrial applications. With a commitment to quality and innovation, we deliver cutting-edge solutions to optimize polymer production. Partner with us for advanced viscosity measurement technology that enhances product quality and process control.
XL7 – D16 SPECIFICATION
|
| |
|
|
PERFORMANCE
|
Range |
0 – 10 8 Pa.S |
| |
Measurement Time |
1 second |
| |
Accuracy |
1% of reading or +/- 1 digit |
| |
Repeatability |
0.3% of reading or +/- 1 digit |
TEMPERATURE
|
Integral Thermometer |
Integrated tip mounted temperature measurement |
| |
Range |
400 °C |
PRESSURE
|
Standard Range |
To process fitting |
PROCESS CONNECTION
|
Standard fitting |
All melt pipe fittings |
| |
Special fitting |
Retrofits for all other viscometer replacements |
ELECTRICAL CONNECTION
|
Cable Length |
As required – not affected by cable length up to 1000m |
| |
Cable Type |
Any standard instrument cable |
| |
Power |
VP Processor powered |
SAFETY CERTIFICATION
|
Hazardous Area |
All instruments available for Ex Hazardous Area, explosive atmospheres |
| |
|
Ga Ex ia IIC T1…T6 |
CONSTRUCTION
|
All welded, crevice-free |
No trap areas or dead-zones for polymer melt |
MATERIALS
|
Head |
SS316 ( EN 1.4401) |
| |
Fitting |
As Required |
| |
Sensor |
SS316 ( EN 1.4401) and SS316L ( EN 1.4404) as standard |
| |
Sensor/Fitting Options |
Alloy C22 (EN 2.4602) |
| |
|
Alloy C276 (EN 2.4819) |
| |
|
S32750 Duplex Steel (EN 1.4410) |
| |
|
Alloy 718 |
| |
Special Materials: |
Non-standard materials to order * |
SURFACE FINISH
|
Standard |
N6 0.8 Ra |
| |
Special Finish |
Non-standard finish options and coatings to order * |
INGRESS PROTECTION
|
Standard |
IP67 |
SOFTWARE
|
ViscoLink data viewing and logging PC software |
| |
|
|
* SPECIAL OPS
|
Custom variations to instrument specification and dimensions routinely provided by our dedicated division |
| |
|
|
